Principle: according to ASTM D792, ASTM D297, GB/T1033, GB/T2951, GB/T3850, GB/T533, HG4-1468, JIS K6268, ISO 2781 and ISO 1183. The Archimedes principle buoyancy method is adopted to accurately and directly read the measured values.
Specification: Model:
JZY-300
JZY-300W
JZY-600W
JZY-120F
Weighing accuracy:
0.01g
0.005g
0.005g
0.001g
Maximum weighing:
300g
300g
600g
120g
Density analysis:
0.001g/cm3
0.001g/cm3
0.001g/cm3
0.0001g/cm3
Measurement type:
Solid, particle, block, floating body, foaming body
Measurement time:
About 10 seconds
Setting function:
Solution compensation setting
Measurement function:
Weight Density Volume
Optional;
printer
Package size;
45 * 24 * 46mm (L * W * H)
weight
6.5kg


Features:

● The densitometer has high measurement accuracy, fast measurement speed, small sample volume and simple operation

● Depending on the characteristics of the products, water, alcohol, silicone oil and other liquids can be replaced as media

● Direct reading of density: only two steps are needed to directly read the density value of the sample

● Adopt the design of "integrated molding large volume", which can easily measure the specific gravity of samples of any shape, including solids, lumps, particles, floats, films, water absorbers, foams, etc.

● It can accurately and quickly measure the density of non absorbent and absorbent products

● Standard RS232 data output function, which can easily connect PC and printer

● Liquid or powder accessories can be purchased to measure the density of liquid or powder

Standard accessories: ① Host  ② Integrated Sink  ③ Measuring table; ④ 100g weight; ⑤ One power transformer; ⑥ Tweezers; ⑦ One set of particle measurement accessories; ⑧ One set of floating body accessories& nbsp; ⑨ Bubble Sipper; ⑩ Wind and dust cover



▼ Solid block measurement steps:

Step 1: Place the tested sample on the upper tray and press the weight in air; Enter  Key automatically memorizes W1 (machine automatically records)

Step 2: Put the object to be tested on the water tray, and press the weight of water; Enter key automatically memorizes W2 (automatically recorded by the machine) for about 3 seconds, and directly displays the density (specific gravity) value

▼ [Steps for measuring plastic particle density meter] (we will provide a set of beakers and tennis balls for measuring plastic particles)

1. First place the beaker on the measuring table and put the tennis ball into the sink. Press the ZERO key to remove the weight

2. Pour the particles into the beaker to measure the weight memory W1 in the air,

3. Pour the particles into the tennis ball in the water to measure the weight memory W2 in the water, and read the density value directly after about 5 seconds

Note: Before measuring the weight of particulate water, it must be cleaned with alcohol to avoid bubbles that may affect the measurement result of W2

▼ [Measure materials with density less than one] (standard anti floating frame for floating body measurement)

Measurement step 1: put the anti floating frame in water and press the zero button to remove the weight

 & nbsp;& nbsp;& nbsp;& nbsp;& nbsp;& nbsp;& nbsp;& nbsp; 2. Put the product on the measuring table to measure the weight in air and record W1; Then put the product into water to measure the weight of water W2, and directly read the density and volume

Note: This machine adopts Archimedes buoyancy method to measure density automatically, and products of any shape can be measured quickly and accurately.
