Variable frequency power supply parameters;
Number of phases
Single phase 1 ￠ 1  in addition
capacity
5KVA
Production method
IGBT/Pulse Width Modulation Type
transport
Voltage (optional)
1￠2W 220V ± 10%
enter
Frequency (optional)
47Hz-63Hz


transport
Electricity& nbsp;& nbsp;& nbsp; Pressure
Low 120V system: 0-190V (Low  Range) Maximum current: High current: 41.6A
High grade 240V system: 0-380V (High Range) High grade current: 20.8A

load regulation
≤& plusmn; 1%

frequency
40.0Hz to499.9Hz (programmable)

Frequency stability
 & nbsp;& le;& plusmn; 0.01%

Harmonic distortion
≤& plusmn; 2%

Frequency meter Hz
4-digit, digital frequency meter, resolution 0.1Hz

Voltmeter V
4-digit, digital voltmeter, resolution 0.1V
Out
Ammeter A
4-digit, digital ammeter, resolution 0.1A

Wattmeter W
4-digit, digital wattmeter, resolution 0.1W/0.1KW
Protector
With overload, short circuit protection and warning device
work
Zhou Wen
0-40deg℃
environment
humidity
0-90% (non condensing state)
volume
（mm）
W*D*Hmm   350*530*675
weight
  KGS
70KGS
500W   1000W   2000W 3000W   5000W   10KVA   15KVA, etc
